Snippet: The story of the EFP

For a while now, the concept of EVC’s (Ethernet Virtual Circuits) and EFP’s (Ethernet Flow Points), has eluded me.

In this short post, i will provide you with a simple example of a couple of EFP’s. In a later post i will discuss the MEF concept of EVC’s.

As always, here is the topology i will be using:

topology

Its a very simple setup. R1 connects to R2 through its G1 interface and connects to R3 through its G2 interface.

On R2 and R3, we have the very common configuration of using subinterfaces for the individual Vlan’s in question. Namely Vlan 10 for the connection between R1 and R2 and Vlan 20 between R1 and R3.

Here is the configuration of R2 and R3:

R2#sh run int g1.10
Building configuration...
Current configuration : 98 bytes
!
interface GigabitEthernet1.10
encapsulation dot1Q 10
ip address 10.10.10.2 255.255.255.0
end

R3#sh run int g1.20
Building configuration...
Current configuration : 98 bytes
!
interface GigabitEthernet1.20
encapsulation dot1Q 20
ip address 10.10.10.3 255.255.255.0
end

Now on R1 is where the “different” configuration takes place:

R1#sh run int g1
Building configuration...
Current configuration : 182 bytes
!
interface GigabitEthernet1
no ip address
negotiation auto
service instance 10 ethernet
encapsulation dot1q 10
rewrite ingress tag pop 1 symmetric
bridge-domain 10
!
end

R1#sh run int g2
Building configuration...
Current configuration : 182 bytes
!
interface GigabitEthernet2
no ip address
negotiation auto
service instance 20 ethernet
encapsulation dot1q 20
rewrite ingress tag pop 1 symmetric
bridge-domain 10
!
end

R1#sh run int bdi10
Building configuration...
Current configuration : 96 bytes
!
interface BDI10
description -= Our L3 interface =-
ip address 10.10.10.1 255.255.255.0
end

So what does this all mean!? – Well, basically what you are looking at is the very nature of an EFP. One on each physical interface in this case. It is defined under the “service instance” command structure.

An Ethernet Flow Point (EFP) is a way to match a certain ethernet frame, do an action on it ingress (and also in our case egress). On top of that you can attach it to a bridge-domain.

The result of the above configuration is that on G1, we match on the dot1q tag when its tagged with vlan 10. On ingress we then pop 1 tag before performing any other “upstream” action. With the symmetric keyword, we attach the vlan 10 tag when egressing.

On G2, we are doing the same, but with vlan 20 instead.

With both EFP’s we attach a bridge-domain (ID 10), which can be verified like this:

R1#show bridge-domain
Bridge-domain 10 (3 ports in all)
State: UP Mac learning: Enabled
Aging-Timer: 300 second(s)
BDI10 (up)
GigabitEthernet1 service instance 10
GigabitEthernet2 service instance 20
AED MAC address Policy Tag Age Pseudoport
- 001E.7AE0.11BF to_bdi static 0 BDI10

Right now we only have one mac address learned, namely of our L3 BDI interface. But we can see that both G1 and G2 has a service instance in this bridge-domain.

Lets try and do some ICMP tests from R2:

R2#ping 10.10.10.1
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 10.10.10.1, timeout is 2 seconds:
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 1/120/598 ms

Lets again verify our bridge-domain on R1:

R1#show bridge-domain
Bridge-domain 10 (3 ports in all)
State: UP Mac learning: Enabled
Aging-Timer: 300 second(s)
BDI10 (up)
GigabitEthernet1 service instance 10
GigabitEthernet2 service instance 20
AED MAC address Policy Tag Age Pseudoport
- 001E.7AE0.11BF to_bdi static 0 BDI10
0 0050.56BE.18D8 forward dynamic 276 GigabitEthernet1.EFP10

What we see now, is that a Mac address has been dynamically learned through the G1.EFP10 EFP.

Since we are technically “bridging” these two distinct vlans, we should be able to ping R3 from R2 as well:

R2#ping 10.10.10.3
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 10.10.10.3, timeout is 2 seconds:
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 2/24/104 ms

And again on R1:

R1#show bridge-domain
Bridge-domain 10 (3 ports in all)
State: UP Mac learning: Enabled
Aging-Timer: 300 second(s)
BDI10 (up)
GigabitEthernet1 service instance 10
GigabitEthernet2 service instance 20
AED MAC address Policy Tag Age Pseudoport
- 001E.7AE0.11BF to_bdi static 0 BDI10
0 0050.56BE.320A forward dynamic 287 GigabitEthernet2.EFP20
0 0050.56BE.18D8 forward dynamic 287 GigabitEthernet1.EFP10

We have now learned all the Mac addresses in our small test environment.

So thats basically all there is to an EFP. A simple way of providing a flexible way of matching frames.

Until next time! – Take care.



New practice lab(s) available…

In case you are serious about going for the CCDE certification, I highly recommend you check out my friend Martin Duggan’s new lab(s) on Leanpub. His writing style is very good and its easy to follow along and i look forward to hitting this lab myself.

So go ahead and pay the man and get an additional CCDE lab for your studies. Take care!

https://leanpub.com/ccdepracticalstudies-practicelab1



Practical DMVPN Example

In this post, I will put together a variety of different technologies involved in a real-life DMVPN deployment.

This includes things such as the correct tunnel configuration, routing-configuration using BGP as the protocol of choice, as well as NAT toward an upstream provider and front-door VRF’s in order to implement a default-route on both the Hub and the Spokes and last, but not least a newer feature, namely Per-Tunnel QoS using NHRP.

So I hope you will find the information relevant to your DMVPN deployments.

First off, lets take a look at the topology I will be using for this example:
Topology

As can be seen, we have a hub router which is connected to two different ISP’s. One to a general purpose internet provider (the internet cloud in this topology) which is being used as transport for our DMVPN setup, as well as a router in the TeleCom network (AS 59701), providing a single route for demonstration purposes (8.8.8.8/32). We have been assigned the 70.0.0.0/24 network from TeleCom to use for internet access as well.

Then we have to Spoke sites, with a single router in each site (Spoke-01 and Spoke-02 respectively).
Each one has a loopback interface which is being announced.

The first “trick” here, is to use the so-called Front Door VRF feature. What this basically allows is to have your transport interface located in a separate VRF. This allows us to have 2 default (0.0.0.0) routes. One used for the transport network and one for the “global” VRF, which is being used by the clients behind each router.

I have created a VRF on the 3 routers in our network (the Hub, Spoke-01 and Spoke-02) called “Inet_VRF”. Lets take a look at the configuration for this network along with its routing information (RIB):


HUB#sh run | beg vrf defi
vrf definition Inet_VRF
!
address-family ipv4
exit-address-family

HUB#sh ip route vrf Inet_VRF | beg Ga
Gateway of last resort is 130.0.0.1 to network 0.0.0.0

S* 0.0.0.0/0 [1/0] via 130.0.0.1
130.0.0.0/16 is variably subnetted, 2 subnets, 2 masks
C 130.0.0.0/30 is directly connected, GigabitEthernet1
L 130.0.0.2/32 is directly connected, GigabitEthernet1

Very simple indeed. We are just using the IPv4 address-family for this VRF and we have a static default route pointing toward the Internet Cloud.

The spokes are very similar:

Spoke-01:





Spoke-01#sh ip route vrf Inet_VRF | beg Gat
Gateway of last resort is 140.0.0.1 to network 0.0.0.0

S* 0.0.0.0/0 [1/0] via 140.0.0.1
140.0.0.0/16 is variably subnetted, 2 subnets, 2 masks
C 140.0.0.0/30 is directly connected, GigabitEthernet1
L 140.0.0.2/32 is directly connected, GigabitEthernet1



Spoke-02:




Spoke-02#sh ip route vrf Inet_VRF | beg Gat
Gateway of last resort is 150.0.0.1 to network 0.0.0.0

S* 0.0.0.0/0 [1/0] via 150.0.0.1
150.0.0.0/16 is variably subnetted, 2 subnets, 2 masks
C 150.0.0.0/30 is directly connected, GigabitEthernet1
L 150.0.0.2/32 is directly connected, GigabitEthernet1



With this in place, we should have full reachability to the internet interface address of each router in the Inet_VRF:


HUB#ping vrf Inet_VRF 140.0.0.2
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 140.0.0.2, timeout is 2 seconds:
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 6/22/90 ms

HUB#ping vrf Inet_VRF 150.0.0.2
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 150.0.0.2, timeout is 2 seconds:
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 4/16/65 ms

With this crucial piece of configuration for the transport network, we can now start building our DMVPN network, starting with the Hub configuration:

HUB#sh run int tun100
Building configuration...



Current configuration : 452 bytes
!
interface Tunnel100
ip address 172.16.0.100 255.255.255.0
no ip redirects
ip mtu 1400
ip nat inside
ip nhrp network-id 100
ip nhrp redirect
ip tcp adjust-mss 1360
load-interval 30
nhrp map group 10MB-Group service-policy output 10MB-Parent
nhrp map group 30MB-Group service-policy output 30MB-Parent
tunnel source GigabitEthernet1
tunnel mode gre multipoint
tunnel vrf Inet_VRF
tunnel protection ipsec profile DMVPN-PROFILE shared
end



There are a fair bit of configuration here. However, pay attention to the “tunnel vrf Inet_VRF” command, as this is the piece that ties into your transport address for the tunnel. So basically we use G1 for the interface, and this is located in the Inet_VRF.

Also notice that we are running crypto on top of our tunnel to protect it from prying eyes. The relevant configuration is here:

crypto keyring MY-KEYRING vrf Inet_VRF
pre-shared-key address 0.0.0.0 0.0.0.0 key SUPER-SECRET
!
!
!
!
!
crypto isakmp policy 1
encr aes 256
hash sha256
authentication pre-share
group 2
!
!
crypto ipsec transform-set TRANSFORM-SET esp-aes 256 esp-sha256-hmac
mode transport
!
crypto ipsec profile DMVPN-PROFILE
set transform-set TRANSFORM-SET



Pretty straightforward with a static pre shared key in place for all nodes.

With the crypto in place, you should have a SA for it installed:


HUB#sh crypto isakmp sa
IPv4 Crypto ISAKMP SA
dst src state conn-id status
130.0.0.2 150.0.0.2 QM_IDLE 1002 ACTIVE
130.0.0.2 140.0.0.2 QM_IDLE 1001 ACTIVE



One for each spoke is in place an in the correct state (QM_IDLE = Good).

So now, lets verify the entire DMVPN solution with a few “show” commands:

HUB#sh dmvpn
Legend: Attrb --> S - Static, D - Dynamic, I - Incomplete
N - NATed, L - Local, X - No Socket
T1 - Route Installed, T2 - Nexthop-override
C - CTS Capable
# Ent --> Number of NHRP entries with same NBMA peer
NHS Status: E --> Expecting Replies, R --> Responding, W --> Waiting
UpDn Time --> Up or Down Time for a Tunnel
==========================================================================

Interface: Tunnel100, IPv4 NHRP Details
Type:Hub, NHRP Peers:2,

# Ent Peer NBMA Addr Peer Tunnel Add State UpDn Tm Attrb
----- --------------- --------------- ----- -------- -----
1 140.0.0.2 172.16.0.1 UP 05:24:09 D
1 150.0.0.2 172.16.0.2 UP 05:24:03 D


We have 2 spokes associated with our Tunnel100. One where the public address (NBMA) is 140.0.02 and the other 150.0.0.2. Inside the tunnel, the spokes have an IPv4 address of 172.16.0.1 and .2 respectively. Also, we can see that these are being learned Dynamically (The D in the 5 column).

All is well and good so far. But we still need to run a routing protocol across the tunnel interface in order to exchange routes. BGP and EIGRP are good candidates for this and in this example I have used BGP. And since we are running Phase 3 DMVPN, we can actually get away with just receiving a default route on the spokes!. At this point remember that our previous default route pointing toward the internet was in the Inet_VRF table, so these two wont collide.

Take a look at the BGP configuration on the hub router:


HUB#sh run | beg router bgp
router bgp 100
bgp log-neighbor-changes
bgp listen range 172.16.0.0/24 peer-group MYPG
network 70.0.0.0 mask 255.255.255.0
neighbor MYPG peer-group
neighbor MYPG remote-as 100
neighbor MYPG next-hop-self
neighbor MYPG default-originate
neighbor MYPG route-map ONLY-DEFAULT-MAP out
neighbor 133.1.2.2 remote-as 59701
neighbor 133.1.2.2 route-map TO-UPSTREAM-SP out



And the referenced route-maps:


ip prefix-list ONLY-DEFAULT-PFX seq 5 permit 0.0.0.0/0
!
ip prefix-list OUR-SCOPE-PFX seq 5 permit 70.0.0.0/24
!
route-map TO-UPSTREAM-SP permit 5
match ip address prefix-list OUR-SCOPE-PFX
!
route-map TO-UPSTREAM-SP deny 10
!
route-map ONLY-DEFAULT-MAP permit 10
match ip address prefix-list ONLY-DEFAULT-PFX



We are using the BGP listen feature, which makes it dynamic to setup BGP peers. We allow everything in the 172.16.0.0/24 network to setup a BGP session and we are using the Peer-Group MYPG for controlling the settings. Notice that we are sending out only a default route to the spokes.

Also pay attention to the fact that we are sending the 70.0.0.0/24 upstream to the TeleCom ISP. Since we are going to use this network for NAT’ing purposes only, we have a static route to Null0 installed as well:


HUB#sh run | incl ip route
ip route 70.0.0.0 255.255.255.0 Null0



For the last part of our BGP configuration, lets take a look at the Spoke configuration, which is very simple and straightforward:


Spoke-01#sh run | beg router bgp
router bgp 100
bgp log-neighbor-changes
redistribute connected route-map ONLY-LOOPBACK0
neighbor 172.16.0.100 remote-as 100



And the associated route-map:


route-map ONLY-LOOPBACK0 permit 10
match interface Loopback0

So basically thats a cookie-cutter configuration thats being reused on Spoke-02 as well.

So what does the routing end up with on the Hub side of things:


HUB# sh ip bgp | beg Networ
Network Next Hop Metric LocPrf Weight Path
0.0.0.0 0.0.0.0 0 i
*>i 1.1.1.1/32 172.16.0.1 0 100 0 ?
*>i 2.2.2.2/32 172.16.0.2 0 100 0 ?
*> 8.8.8.8/32 133.1.2.2 0 0 59701 i
*> 70.0.0.0/24 0.0.0.0 0 32768 i

We have a default route, which we injected using the default-information originate command. Then we receive the loopback addresses from each of the two spokes. Finally we have the network statement, the hub inserted, sending it to the upstream TeleCom. Finally we have 8.8.8.8/32 from TeleCom 🙂

Lets look at the spokes:


Spoke-01#sh ip bgp | beg Network
Network Next Hop Metric LocPrf Weight Path
*>i 0.0.0.0 172.16.0.100 0 100 0 i
*> 1.1.1.1/32 0.0.0.0 0 32768 ?

Very straightforward and simple. A default from the hub and the loopback we ourself injected.

Right now, we are in a situation where we have the correct routing information and we are ready to let NHRP do its magic. Lets take a look what happens when Spoke-01 sends a ping to Spoke-02’s loopback address:


Spoke-01#ping 2.2.2.2 so loo0
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 2.2.2.2, timeout is 2 seconds:
Packet sent with a source address of 1.1.1.1
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 8/17/32 ms

Everything works, and we the math is right, we should see an NHRP shortcut being created for the Spoke to Spoke tunnel:


Spoke-01#sh ip nhrp shortcut
2.2.2.2/32 via 172.16.0.2
Tunnel100 created 00:00:06, expire 01:59:53
Type: dynamic, Flags: router rib
NBMA address: 150.0.0.2
Group: 30MB-Group
172.16.0.2/32 via 172.16.0.2
Tunnel100 created 00:00:06, expire 01:59:53
Type: dynamic, Flags: router nhop rib
NBMA address: 150.0.0.2
Group: 30MB-Group

and on Spoke-02:


Spoke-02#sh ip nhrp shortcut
1.1.1.1/32 via 172.16.0.1
Tunnel100 created 00:01:29, expire 01:58:31
Type: dynamic, Flags: router rib
NBMA address: 140.0.0.2
Group: 10MB-Group
172.16.0.1/32 via 172.16.0.1
Tunnel100 created 00:01:29, expire 01:58:31
Type: dynamic, Flags: router nhop rib
NBMA address: 140.0.0.2
Group: 10MB-Group

And the RIB on both routers should reflect this as well:


Gateway of last resort is 172.16.0.100 to network 0.0.0.0



B* 0.0.0.0/0 [200/0] via 172.16.0.100, 06:09:37
1.0.0.0/32 is subnetted, 1 subnets
C 1.1.1.1 is directly connected, Loopback0
2.0.0.0/32 is subnetted, 1 subnets
H 2.2.2.2 [250/255] via 172.16.0.2, 00:02:08, Tunnel100
172.16.0.0/16 is variably subnetted, 3 subnets, 2 masks
C 172.16.0.0/24 is directly connected, Tunnel100
L 172.16.0.1/32 is directly connected, Tunnel100
H 172.16.0.2/32 is directly connected, 00:02:08, Tunnel100

The “H” routes are from NHRP

And just to verify that our crypto is working, heres a capture from wireshark on the internet “Cloud” when pinging from Spoke-01 to Spoke-02:

wireshark

Now lets turn our attention to the Quality of Service aspect of our solution.

We have 3 facts to deal with.

1) The Hub router has a line-rate Gigabit Ethernet circuit to the Internet.
2) The Spoke-01 site has a Gigabit Ethernet circuit, but its a subrate to 10Mbit access-rate.
3) The Spoke-02 site has a Gigabit Ethernet circuit, but its a subrate to 30Mbit access-rate.

We somehow want to signal to the Hub site to “respect” these access-rates. This is where the “Per-Tunnel QoS” feature comes into play.

If you remember the Hub tunnel100 configuration, which looks like this:


interface Tunnel100
ip address 172.16.0.100 255.255.255.0
no ip redirects
ip mtu 1400
ip nat inside
ip nhrp network-id 100
ip nhrp redirect
ip tcp adjust-mss 1360
load-interval 30
nhrp map group 10MB-Group service-policy output 10MB-Parent
nhrp map group 30MB-Group service-policy output 30MB-Parent
tunnel source GigabitEthernet1
tunnel mode gre multipoint
tunnel vrf Inet_VRF
tunnel protection ipsec profile DMVPN-PROFILE shared



We have these 2 “nhrp map” statements. What these in effect does is to provide a framework for the Spokes to register using one of these two maps for the Hub to use to that individual spoke.

So these are the policy-maps we reference:


HUB#sh policy-map
Policy Map 30MB-Child
Class ICMP
priority 5 (kbps)
Class TCP
bandwidth 50 (%)

Policy Map 10MB-Parent
Class class-default
Average Rate Traffic Shaping
cir 10000000 (bps)
service-policy 10MB-Child

Policy Map 10MB-Child
Class ICMP
priority 10 (%)
Class TCP
bandwidth 80 (%)


Policy Map 30MB-Parent
Class class-default
Average Rate Traffic Shaping
cir 30000000 (bps)
service-policy 30MB-Child



We have a hiearchical policy for both the 10Mbit and 30Mbit groups. each with their own child policies.

On the Spoke side of things, all we have to do is to tell the Hub which group to use:


interface Tunnel100
bandwidth 10000
ip address 172.16.0.1 255.255.255.0
no ip redirects
ip mtu 1400
ip nhrp map 172.16.0.100 130.0.0.2
ip nhrp map multicast 130.0.0.2
ip nhrp network-id 100
ip nhrp nhs 172.16.0.100
ip nhrp shortcut
ip tcp adjust-mss 1360
load-interval 30
nhrp group 10MB-Group
qos pre-classify
tunnel source GigabitEthernet1
tunnel mode gre multipoint
tunnel vrf Inet_VRF
tunnel protection ipsec profile DMVPN-PROFILE



Here on Spoke-01, we request that the QoS group to be used is 10MB-Group.

And on Spoke-02:


interface Tunnel100
bandwidth 30000
ip address 172.16.0.2 255.255.255.0
no ip redirects
ip mtu 1400
ip nhrp map 172.16.0.100 130.0.0.2
ip nhrp map multicast 130.0.0.2
ip nhrp network-id 100
ip nhrp nhs 172.16.0.100
ip nhrp shortcut
ip tcp adjust-mss 1360
load-interval 30
nhrp group 30MB-Group
qos pre-classify
tunnel source GigabitEthernet1
tunnel mode gre multipoint
tunnel vrf Inet_VRF
tunnel protection ipsec profile DMVPN-PROFILE



We request the 30MB-Group.

So lets verify that the Hub understands this and applies it accordingly:


HUB#sh nhrp group-map
Interface: Tunnel100
NHRP group: 10MB-Group
QoS policy: 10MB-Parent
Transport endpoints using the qos policy:
140.0.0.2



NHRP group: 30MB-Group
QoS policy: 30MB-Parent
Transport endpoints using the qos policy:
150.0.0.2



Excellent. and to see that its actually applied correctly:


HUB#sh policy-map multipoint tunnel 100



Interface Tunnel100 <--> 140.0.0.2

Service-policy output: 10MB-Parent

Class-map: class-default (match-any)
903 packets, 66746 bytes
30 second offered rate 0000 bps, drop rate 0000 bps
Match: any
Queueing
queue limit 64 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 900/124744
shape (average) cir 10000000, bc 40000, be 40000
target shape rate 10000000

Service-policy : 10MB-Child

queue stats for all priority classes:
Queueing
queue limit 512 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 10/1860

Class-map: ICMP (match-all)
10 packets, 1240 bytes
30 second offered rate 0000 bps, drop rate 0000 bps
Match: protocol icmp
Priority: 10% (1000 kbps), burst bytes 25000, b/w exceed drops: 0
Class-map: TCP (match-all)
890 packets, 65494 bytes
30 second offered rate 0000 bps, drop rate 0000 bps
Match: access-group 110
Queueing
queue limit 64 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 890/122884
bandwidth 80% (8000 kbps)

Class-map: class-default (match-any)
3 packets, 12 bytes
30 second offered rate 0000 bps, drop rate 0000 bps
Match: any

queue limit 64 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 0/0

Interface Tunnel100 <--> 150.0.0.2

Service-policy output: 30MB-Parent

Class-map: class-default (match-any)
901 packets, 66817 bytes
30 second offered rate 0000 bps, drop rate 0000 bps
Match: any
Queueing
queue limit 64 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 901/124898
shape (average) cir 30000000, bc 120000, be 120000
target shape rate 30000000

Service-policy : 30MB-Child

queue stats for all priority classes:
Queueing
queue limit 512 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 10/1860

Class-map: ICMP (match-all)
10 packets, 1240 bytes
30 second offered rate 0000 bps, drop rate 0000 bps
Match: protocol icmp
Priority: 5 kbps, burst bytes 1500, b/w exceed drops: 0
Class-map: TCP (match-all)
891 packets, 65577 bytes
30 second offered rate 0000 bps, drop rate 0000 bps
Match: access-group 110
Queueing
queue limit 64 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 891/123038
bandwidth 50% (15000 kbps)

Class-map: class-default (match-any)
0 packets, 0 bytes
30 second offered rate 0000 bps, drop rate 0000 bps
Match: any

queue limit 64 packets
(queue depth/total drops/no-buffer drops) 0/0/0
(pkts output/bytes output) 0/0


The last piece of the QoS puzzle is to make sure you have a service-policy applied on the transport interfaces on the spokes as well:


Spoke-01#sh run int g1
Building configuration...

&nbsp;


Current configuration : 210 bytes
!
interface GigabitEthernet1
description -= Towards Internet Router =-
bandwidth 30000
vrf forwarding Inet_VRF
ip address 140.0.0.2 255.255.255.252
negotiation auto
service-policy output 10MB-Parent
end



and on Spoke-02:


poke-02#sh run int g1
Building configuration...

&nbsp;


Current configuration : 193 bytes
!
interface GigabitEthernet1
description -= Towards Internet Router =-
vrf forwarding Inet_VRF
ip address 150.0.0.2 255.255.255.252
negotiation auto
service-policy output 30MB-Parent
end



The last thing i want to mention is the NAT on the hub to use the 70.0.0.0/24 network for the outside world. Pretty straight forward NAT (inside on the tunnel interface 100 and outside on the egress interface toward Telecom, G2):


HUB#sh run int g2
Building configuration...

&nbsp;


Current configuration : 106 bytes
!
interface GigabitEthernet2
ip address 133.1.2.1 255.255.255.252
ip nat outside
negotiation auto
end



Also the NAT configuration itself:


ip nat pool NAT-POOL 70.0.0.1 70.0.0.253 netmask 255.255.255.0
ip nat inside source list 10 pool NAT-POOL overload
!
HUB#sh access-list 10
Standard IP access list 10
10 permit 1.1.1.1
20 permit 2.2.2.2



We are only NAT’ing the two loopbacks from the spokes on our network.

Lets do a final verification on the spokes to 8.8.8.8/32:




Spoke-01#ping 8.8.8.8 so loo0
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 8.8.8.8, timeout is 2 seconds:
Packet sent with a source address of 1.1.1.1
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 12/23/56 ms

and Spoke-02:


Spoke-02#ping 8.8.8.8 so loo0
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 8.8.8.8, timeout is 2 seconds:
Packet sent with a source address of 2.2.2.2
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 10/14/27 ms



Lets verify the NAT state table on the hub:


HUB#sh ip nat trans
Pro Inside global Inside local Outside local Outside global
icmp 70.0.0.1:1 1.1.1.1:5 8.8.8.8:5 8.8.8.8:1
icmp 70.0.0.1:2 2.2.2.2:0 8.8.8.8:0 8.8.8.8:2
Total number of translations: 2



All good!.

I hope you have had a chance to look at some of the fairly simple configuration snippets thats involved in these techniques and how they fit together in the overall scheme of things.

If you have any questions, please let me know!

Have fun with the lab!

(Configurations will be added shortly!)

1st Attempt – No Dice

So I just got back from my first attempt at the CCDE practical, and unfortunally I didnt pass it.
It was a very different exam than the CCIE and it takes a little while to become used to the interface and exam style.

I started my journey to London on the 30th of August and right off the bat it started out badly with me getting an eye infection in one eye. By the end of the day it had spread to my other eye. Not really what you want or need going into an exam which is heavy on the reading part.

However, it was awesome meeting some of my study buddies from our Slack group! We had a great meal and a few good beers! – Time to call it a night.

The exam has been documented elsewhere, so i wont spend much time on it here. Suffice it to say its a difficult beast 🙂

I only used 5.5 hours of my 9 hour slot, and i just wanted to get out of there and rest my eyes to be honest.

I departed London September 1st and im now back at work. Much the wiser however.

I now know how the exam feels like and the delivery method. I also know what sort of questions are being asked of you and in what detail.

I do need to make up my mind about whether to try the November date or go for the February one. With all the stuff going on in my life at the moment (now being a home-owner), im leaning towards the February one.

Time to get back to work! 🙂

Cisco Live US! 2016

I am fortunate enough, to be able to goto Cisco Live US! again this year.
Last year was such an experience, that my hopes are really high for this year as well.

I will be arriving on Friday the 8th and leaving on the 15th. Not a long stay this time, but it was what my boss could arrange for.
Again this year I will be bringing my better half, so she can experience the city and hopefully we’ll get a few hours of sightseeing in between commitments.

One of the things that im really looking forward to, is meeting up with friends and peers. This year is a bonus for me, as I get to say Congratulations to my friend Daniel (lostintransit.se) in person and not just on the phone, on passing the CCDE practical exam!

Also, a first for me, will be meeting up with Darren (mellowd.co.uk). We have been talking for a long time on twitter, mail and webex and im really looking forward to meeting him in person.

When we get closer to the event, I will be posting my Cisco Live! schedule here.

If you happen to be around the Las Vegas area, or even at Cisco Live!, drop me a line and maybe we can meet up!

See you there!

GETVPN Example

A couple of weeks ago I had the good fortune of attending Jeremy Filliben’s CCDE Bootcamp.
It was a great experience, which I will elaborate on in another post. But one of the technology areas I had a bit of difficult with, was GETVPN.

So in this post a I am going to setup a scenario in which a customer has 3 sites, 2 “normal” sites and a Datacenter site. The customer wants to encrypt traffic from Site 1 to Site 2.

Currently the customer has a regular L3VPN service from a provider (which is beyond the scope of this post). There is full connectivity between the 3 sites through this service.

The topology is as follows:

Topology

GETVPN consists of a few components, namely the Key Server (KS) and Group Members (GM’s), which is where it derives its name: Group Encrypted Transport. A single SA (Security Association) is used for the encryption. The Key Server distributes the information to the Group Members through a secure transport, where the Group Members then use this information (basically an ACL) to encrypt/decrypt the data packets.

The routing for the topology is fairly simple. (See Routing Diagram) Each client as well as the KeyServer uses a default route to reach the rest of the topology. Each CE router runs eBGP with the provider, where it redistributes the conntected interfaces into BGP for full reachability between the sites.

Routing-Topology

At this point, lets verify that we have full connectivty through the L3VPN SP.

On CE-1:

CE1#sh ip bgp
BGP table version is 7, local router ID is 192.168.12.2
Status codes: s suppressed, d damped, h history, * valid, > best, i - internal,
              r RIB-failure, S Stale, m multipath, b backup-path, f RT-Filter,
              x best-external, a additional-path, c RIB-compressed,
Origin codes: i - IGP, e - EGP, ? - incomplete
RPKI validation codes: V valid, I invalid, N Not found

     Network          Next Hop            Metric LocPrf Weight Path
 *>  10.10.1.0/24     0.0.0.0                  0         32768 ?
 *>  10.10.2.0/24     10.10.1.2                              0 100 100 ?
 *>  10.10.3.0/24     10.10.1.2                              0 100 100 ?
 *>  192.168.12.0     0.0.0.0                  0         32768 ?
 *>  192.168.23.0     10.10.1.2                              0 100 100 ?
 *>  192.168.34.0     10.10.1.2                              0 100 100 ?

We are learning the routes to the other sites.

And connectivity from Client-1:

Client-1#ping 192.168.34.1
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 192.168.34.1, timeout is 2 seconds:
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max = 1/10/25 ms

The interesting part takes place on the KeyServer along wi th CE1 and CE3.

If we take a look at the configuration on the KeyServer.

First off, we have a regular extended ACL that defines what traffic we want to encrypt. This ACL is the one that gets “downloaded” to CE1 and CE3:

ip access-list extended CRYPTO_ACL
 permit ip 192.168.12.0 0.0.0.255 192.168.34.0 0.0.0.255
 permit ip 192.168.34.0 0.0.0.255 192.168.12.0 0.0.0.255




Register-ACL-Download

Next up we have an ISAKMP policy which is used during the information communication with the KeyServer. This policy is present on all the Group Members (GM’s) and the KeyServer:

crypto isakmp policy 10
 encr aes 256
 hash sha256
 authentication pre-share
 group 2
crypto isakmp key SUPERSECRET address 0.0.0.0

In this example we use a simple Pre Shared Key with the Any address form. This can (and probably should) be either certificate based. However, this complicates matters, so i skipped that.

Next is the transform set for IPsec which will be used. Notice that we use tunnel mode.

crypto ipsec transform-set GET-VPN-TRANSFORM-SET esp-aes esp-sha256-hmac
 mode tunnel

This transform set is being referenced in a IPsec profile configuration:

crypto ipsec profile GETVPN-PROFILE
 set transform-set GET-VPN-TRANSFORM-SET

This is nesecary in order for the next configuration, which is the entire GDOI aspect:

crypto gdoi group GDOI-GROUP
 identity number 100
 server local
  rekey authentication mypubkey rsa GETVPN-KEY
  rekey transport unicast
  sa ipsec 1
   profile GETVPN-PROFILE
   match address ipv4 CRYPTO_ACL
   replay counter window-size 64
   no tag
  address ipv4 192.168.23.1

Here we are creating a GDOI configuration, where we have a unique identifier for this group configuration (100). We are telling the router that its the server. Next is the public key we have created with an name this time (“crypto key generate rsa label “). This is used for rekeying purposes. And notice that we are using unicasting for the key material. This could just as well have been multicast, but again, that requires you have your infrastructure multicast capable and ready.

We then reference our previous IPsec profile and specify our crypt “ACL”. Lastly we specify which “update source” should be used for this server (which the other GM’s will use to communicate to/from).

If we then match this to what is configured on CE1 and CE3:

crypto isakmp policy 10
 encr aes 256
 hash sha256
 authentication pre-share
 group 2
crypto isakmp key SUPERSECRET address 0.0.0.0
crypto gdoi group GDOI-GROUP
 identity number 100
 server address ipv4 192.168.23.1
crypto map MYMAP 10 gdoi
 set group GDOI-GROUP
 crypto map MYMAP

And on the interface towards the SP we apply the crypto map:

CE1#sh run int g1.10
Building configuration...

Current configuration : 115 bytes
!
interface GigabitEthernet1.10
 encapsulation dot1Q 10
 ip address 10.10.1.1 255.255.255.0
 crypto map MYMAP
end



Crypto Map Topology

We can see that we have the ISAKMP configuration which I mentioned thats being used for a secure communication channel. Next we simply have the location of our KeyServer and the Identifier and thats pretty much all. Everything else is being learned from the Key Server.

After everything has been configured, you can see the log showing the registration process:

*May 15 10:37:53.245: %CRYPTO-5-GM_REGSTER: Start registration to KS 192.168.23.1 for group GDOI-GROUP using address 10.10.3.1 fvrf default ivrf default
*May 15 10:38:23.356: %GDOI-5-SA_TEK_UPDATED: SA TEK was updated
*May 15 10:38:23.395: %GDOI-5-SA_KEK_UPDATED: SA KEK was updated 0x5DB57E80F97A9A1DC16B9DBBCF7CB169
*May 15 10:38:23.395: %GDOI-5-GM_REGS_COMPL: Registration to KS 192.168.23.1 complete for group GDOI-GROUP using address 10.10.3.1 fvrf default ivrf default
*May 15 10:38:23.668: %GDOI-5-GM_INSTALL_POLICIES_SUCCESS: SUCCESS: Installation of Reg/Rekey policies from KS 192.168.23.1 for group GDOI-GROUP & gm identity 10.10.3.1 fvrf default ivrf default

Another form of verification is the “show crypto gdoi” command structure, which gives you alot of information on the process:

CE1#sh crypto gdoi
GROUP INFORMATION

    Group Name               : GDOI-GROUP
    Group Identity           : 100
    Group Type               : GDOI (ISAKMP)
    Crypto Path              : ipv4
    Key Management Path      : ipv4
    Rekeys received          : 0
    IPSec SA Direction       : Both

     Group Server list       : 192.168.23.1

Group Member Information For Group GDOI-GROUP:
    IPSec SA Direction       : Both
    ACL Received From KS     : gdoi_group_GDOI-GROUP_temp_acl

    Group member             : 10.10.1.1       vrf: None
       Local addr/port       : 10.10.1.1/848
       Remote addr/port      : 192.168.23.1/848
       fvrf/ivrf             : None/None
       Version               : 1.0.16
       Registration status   : Registered
       Registered with       : 192.168.23.1
       Re-registers in       : 1580 sec
       Succeeded registration: 1
       Attempted registration: 3
       Last rekey from       : 0.0.0.0
       Last rekey seq num    : 0
       Unicast rekey received: 0
       Rekey ACKs sent       : 0
       Rekey Received        : never
       DP Error Monitoring   : OFF
       IPSEC init reg executed    : 0
       IPSEC init reg postponed   : 0
       Active TEK Number     : 1
       SA Track (OID/status) : disabled

       allowable rekey cipher: any
       allowable rekey hash  : any
       allowable transformtag: any ESP

    Rekeys cumulative
       Total received        : 0
       After latest register : 0
       Rekey Acks sents      : 0

 ACL Downloaded From KS 192.168.23.1:
   access-list   permit ip 192.168.12.0 0.0.0.255 192.168.34.0 0.0.0.255
   access-list   permit ip 192.168.34.0 0.0.0.255 192.168.12.0 0.0.0.255

KEK POLICY:
    Rekey Transport Type     : Unicast
    Lifetime (secs)          : 84613
    Encrypt Algorithm        : 3DES
    Key Size                 : 192
    Sig Hash Algorithm       : HMAC_AUTH_SHA
    Sig Key Length (bits)    : 2352

TEK POLICY for the current KS-Policy ACEs Downloaded:
  GigabitEthernet1.10:
    IPsec SA:
        spi: 0xA3D6592E(2748733742)
        KGS: Disabled
        transform: esp-aes esp-sha256-hmac
        sa timing:remaining key lifetime (sec): (1815)
        Anti-Replay(Counter Based) : 64
        tag method : disabled
        alg key size: 16 (bytes)
        sig key size: 32 (bytes)
        encaps: ENCAPS_TUNNEL

Among the most interesting is the KEK policy and the ACL thats in place.

If we then verify from Client-1, we can see that we have a couple of seconds timeout while the encryption is being setup, and from there we have connectivity:

Client-1#ping 192.168.34.1
Type escape sequence to abort.
Sending 5, 100-byte ICMP Echos to 192.168.34.1, timeout is 2 seconds:
..!!!
Success rate is 60 percent (3/5), round-trip min/avg/max = 2/2/2 ms

So from something thats in theory very complex, this is very efficient from a both a configuration as well as a control-plane point of view. I know it certainly helped me understand the steps involved in setting GETVPN to create this lab, so I hope its been relevant for you as well!

February – A busy month indeed!

Wow, what a busy month this has been!

So I started my new job on February 1st and thus far, everything has been really great.
My new coworkers are very friendly and helpful.

I’ve spent the better part of february, trying to get to grips with the SP network I will be focusing on from now on. Im still not where I want to be yet, but im getting there. One of the guys I will be working very closely with, started cleaning up the network when he was hired 9 months ago and he’s done a really great job with what he’s had to work with.

There are still some work to be done however, which is the very reason they have hired me and another very good friend of mine. A well run network is a dynamic beast which needs to be tamed. On top of that, the company growth has been around 30% a year, so alot of structure and processes needs to come with that growth, which is where I can really make a difference.

I’ve also had the good fortune of being selected as a 2016 Cisco Champion, which was a very nice surprise. I tried to squeeze in a few good technical posts last year, which I hope was useful to someone on the net. I’ve attended a few briefings so far, but they have mainly been about topics which I dont know enough about to offer any commentary on (UCS for example). Im hoping they are working on something in the routing realm as well 🙂

So for 2016, my primary objective is as previously stated, the CCDE certification.
Next month is Jeremy Filliben’s CCDE bootcamp, which I will be attending. I hope this will kick my butt into gear (I knew the change of jobs would hit my CCDE preparation). Im still aiming for a shot at the practical in late August.

Our Slack study group (Which Daniel Dib and I started) has grown quite a bit and includes a fair number of experts in different areas. If you are serious about CCDE or network design in general, dont be shy to mail me for an invite.

There are however, technologies which I also want to be familiar with to the level of blogging about them.

These include:

– Practical Segment Routing.
– Cisco’s iWAN solution.
– A deep knowledge of the ASR9K platform.
– Programmability (Python, API’s, etc.).
Now, back to work I go 🙂

/Kim

Doing right in the VAR role!

This post is my follow-up on a recent discussion on twitter.

Working for a VAR (Value Added Reseller) is not always the glamours life some make it out to be.

Working as a consultant, what you are really doing, is being the CEO of your own service company.
What you are selling, is basically your own services. The fact that your paycheck is being signed by someone else doesnt/shouldnt really matter.

The customer is building a relationship with you, as much as the company you are working for.
On top of that, you are continually building rapor in the networking world, so in my opinion, I would rather leave the customer with a good solution, rather than having to stick with the insane budgets that sales people end up shaving a project down to, just to get the contract.

So what can you do to create the outcome that is beneficial for all parties concerned (The customer, Your employer and yourself)?

Well, what I have tried in the past, is try and emphasize the importance of leaving the customer with the right solution based on his/her requirements and constraints. This discussion should involve both the technical side of things, as well as any account manager(s)/sales people involved. Try and focus on the long term results, such as customer satisfaction and reoccurring sales because of it.

Toward the customer, do your best to explain why solution X is better than Y, because of the requirements that are in place. Most people are sensible enough that, if you just take your time to explain the solution and have your reasoning in place, they will understand. Both of these (explaining and reasoning), is important for you to build the before mentioned rapor with the customer.

In the end, you should end up with a customer that will ask you for advice when in need, and trust your judgement when you recommend a solution. By doing this you effectively put the “fluff” from the account manager(s) aside and focus on the important work.

As engineers, we tend to focus on the technical side of a solution, but to be successful in our role(s), we also need to pay attention to the human/social aspect. Personally, this is an ongoing exercise, which I try to be very cognitive about when engaging with the customer.

So to summarize:

– Be a teamplayer, but know you are the one who has to face the customer regularly.
– Do your best to understand the customer and his/her requirements.
– Take your time to explain your solution to the customer.
– Never take the customer for granted.
– Pay attention to the social/human aspect when engaging with both the customer and your coworkers.

Now go and have a sit-down with that customer of yours!

/Kim

Passed the CCDE written. Now what?

I was fortunate enough to finally pass the CCDE written exam yesterday morning.

That begs the question of “Now What?”

Well, I will spend a couple of days putting together a study strategy, based on where I am now compared to where I need to be in order to pass the exam. As it looks now, I am probably going for a fall 2016 exam date. That gives me enough time to settle into a new job with everything that entails.

It also means that I will need to spend 2-3 hours of study per day (some weekends more than that), with a combination of watching Cisco Live 365 videos and reading CVD’s/Books.

On top of that, my good friend Daniel Dib and I, along with hopefully a few others will have some design discussions using Webex. We have been told its really important to iron out different design ideas with other people. Especially if we can get a group together with people from different areas of expertise (Datacenter, Service Provider, Enterprise etc.).

Alas, an update to this story will come shortly! 🙂

Take care!

Time for change

Its time for a change!

It was a tough decision, but i’ve decided that I need some new challenges in my professional life. To that effect, i’ve quit my old job and joined a different VAR/SP where I will be working in a skilled team of network engineers.

My duties will include maintaining and expanding a growing MPLS network, with all the services one can build on top of such a beast. Along with that, I will be attached to large enterprise customers, helping with design and implementation.

The new job is very supportive of my effort to go after the elusive CCDE certification, which was a big part of my decision as well, so expect more updates in that direction!

I’ve had some great years with awesome coworkers, but I have great confidence in the coming years as well!

Finally, a big thanks to my family and friends for supporting me through this decision process!

/Kim
